Equipped with a nozzle exchange station, allowing for simultaneous installation of both large and small materials on a single machine;
Standard tray material station is equipped, and woven tray materials can be loaded simultaneously;
Each group of mounting heads independently controls the rotation angle, resulting in higher mounting efficiency;
The highest efficiency of DOB component mounting can reach 18000 chips/h;
Can choose high-precision linear motor, X-axis, Y-axis gantry dual drive;
SMT material 0402-22mm in length and height, various components, etc;
Suitable for: DOB light sources, small household appliances, control boards, point light sources, etc.
