1. The heating system adopts ONLYSMT patented heating technology.

2. Adopt Taiwan Yangming high current solid state relay non-contact output, safe and reliable, equipped with special SSR radiator, heat dissipation efficiency is greatly improved, effectively extend its service life.

3. The heating parts use imported high-quality components to ensure the high stability and reliability of the whole system, and ensure a long service life.

4. Combined with the unique temperature instrument control function of the thermostat, it has been monitoring the change of external temperature and heat value, controlling the heating device with the minimum pulse, quickly responding to ensure the temperature control accuracy, the temperature distribution error in the machine is minimal, and the temperature distribution in the length direction meets the IPC standard.

5. Precision controller of intelligent operation of temperature instrument, through intelligent operation of temperature instrument, automatic control of heat, fuzzy control function responds to changes of external heat at the fastest speed and ensures more balanced temperature through internal control.

6. With temperature overshoot, fault diagnosis, sound and light alarm function.

7. Independent small circulation air design, upper and lower heating mode, good thermal compensation, high thermal efficiency, power saving, fast heating speed, suitable for BGA and CSP components and other high-quality products welding. Special forced hot air circulation structure system, so that PCB and components are heated evenly, high efficiency, fast heating speed.

8. The air transport system adopts advanced air duct design, and the imported air transport system is equipped with a three-layer air equalization device, which ensures uniform air transport and high heat exchange efficiency.

9. The preheating zone, welding zone and cooling zone are heated independently, with independent circulation and independent temperature control. The temperature difference between adjacent temperature zones can reach 100℃, and the temperature and wind speed in each temperature zone can be adjusted independently.

10. Taiwan Sanyue high temperature motor directly connected to drive hot air circulation, hot air balance is good, smooth operation, long life, low dryness, small vibration.

11. The power of each temperature zone is properly matched, and the temperature is heated rapidly, from room temperature to the set working temperature for about 15 minutes. And has fast and efficient thermal compensation performance.

12. Modular design, compact structure, easy maintenance. The independent cooling zone ensures the required low temperature when the PCB board comes out.

13. The transmission system adopts Japanese Panasonic motor, temperature instrument full closed-loop speed regulation, with 1:150 imported turbine reducer, smooth operation, speed adjustable range 0-1600mm/min.

14. Using independent roller structure and top support, combined with stainless steel mesh belt, smooth operation, speed up to ±10mm/min, especially suitable for BGA\CSP and 0201 welding.

15. Special stainless steel B mesh belt, durable and wear-resistant. It is not easy to change after long use.

16. Guide rail + mesh belt transportation can be selected according to needs

17. Delay switch protection function, uniform cooling after shutdown, effectively prevent the deformation of components caused by uneven cooling.
